1060 cable aluminum strip uses and specifications

Product: 1060 aluminum cable strip

Tempers: O/HO, H14, H24

Thickness: 0.08–3.0mm

Width: 10–1500mm

Conductivity: 1060-O≥61.5% IACS

Elongation: >25%

Max. 20℃ resistance: ≤0.02825Ωmm2/m

20℃ density: 2.703 kg/m3

Coil ID: 150mm, 300mm, 400mm, 500mm

Surface treatment: smooth surface, no scratches and impurities

Protection: Paper Interleaved/film covered

Packing: eye to wall, eye to sky, wooden pallet

Cable aluminum strip/tape is a versatile metal material that can be used to make various types of cables and wires. 1060 cable aluminum strip has good electrical conductivity and wear resistance, and can effectively resist electromagnetic interference. Cable aluminum strips are widely used in electric power, communications, petroleum, chemical and other industries. 1060 cable aluminum strip is one of the most commonly used materials, and its specifications are mainly divided into: width and thickness. Depending on the use, common widths are 3mm, 5mm, 10mm, 15mm and 20mm, while common thicknesses are 0.2mm, 0.5mm and 1mm.

Features of 1060 cable aluminum strip

• Excellent electrical conductivity

1060 Aluminum strips have excellent electrical conductivity, which can effectively avoid current leakage in cable lines and improve the transmission efficiency of cable lines.

• Good corrosion resistance

1060 Aluminum strips have the characteristics of good corrosion resistance, which can effectively prevent corrosion in cable lines and improve the service life of cable lines.

• Good wear resistance

Aluminum strips have the characteristics of good wear resistance, which can effectively prevent wear and tear in cable lines and improve the service life of cable lines.

• Excellent insulation performance

Aluminum strip has the characteristics of excellent insulation performance, which can effectively prevent electromagnetic wave interference in cable lines and improve the transmission efficiency of cable lines.

Uses of 1060 cable aluminum strip

• Aluminum strip for electric power

1060 aluminum strip is mainly used as a conductor in high-voltage power transmission projects and urban distribution networks. Its surface is treated by hot-dip galvanizing process, which has excellent anti-corrosion properties; it can also effectively prevent oxidation and extend its service life. The product is mainly suitable for use in overhead bare wires of various voltage levels and core wires or insulation layers of underground distribution lines.

• Aluminum strip for communication

1060 aluminum strip is mainly used in optical cable transmission systems and indoor distribution systems in long-distance communication networks. It has the advantages of good anti-electromagnetic interference, good mechanical strength and elongation; it can also be coated according to different requirements. Treated to enhance corrosion resistance and decorative properties.

• Petrochemical industry

1060 aluminum strip is mainly used as wire protection tube on pipelines transporting media such as crude oil and natural gas; it can also be used as the lining of oil well pipelines.

• Automobile industry

1060 aluminum strip can be used in the gasket between the battery guide rail cover and the window glass in the car, as well as the door lock handle, etc.; it can also be used as parts of other industrial products, such as the connector between the hood cover and the chassis, instruments board supports, etc.
