1070 Aluminum Coil

Alloy: 1070
Temper(mm): O,H22,H24,H26,H18,etc.
Width(mm): 100-2650
Thickness(mm): 0.15-6
Length(mm): C

Quick Quote Get A Quote

The Introduction of 1070 Aluminum Coil

1070 aluminum coil belongs to series 1 pure aluminum, containing 99.7% aluminum. It has good electrical and thermal conductivity, high plasticity and corrosion resistance. 1070 aluminum coil cannot be strengthened by heat treatment, its strength is not high, and its machinability is not good, but it can be welded if necessary. It is often used to manufacture structural parts with specific properties, such as protective nets, wire cores and coils for wires and cables, and aircraft ventilation system parts.

1070 aluminum coil

The Product Specification of 1070 Aluminum Coil

Alloy	1070
Temper	O,H12,H14,H16,H18,H22,H24,H32,H34,H36,H38,etc.
Thickness (mm)	0.15-6
Width (mm)	100-2650
Length (mm)	C
ID	Ø505mm or customized
Package	Eye to sky or Eye to wall
Application	Radiator, charging pile, anti-corrosion insulation, transformers, aircraft ventilation system parts, etc.

Chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Zr	Others		AL
1070	0.20	0.25	0.03	0.03	0.03	-	0.07	0.03	-	Single	Total	99.70
										0.03	-

Mechanical properties:

Alloy & Temper	Tensile strengthRm/Mpa	Yield strengthRp0.2/Mpa
1070-O	55-95	0-15

The Product Features of 1070 Aluminum Coil

1070 Aluminum coil has high plasticity, corrosion resistance, electrical conductivity and thermal conductivity.
1070 Aluminum coil can be welded by gas welding, hydrogen atom welding and contact welding.
1070 Aluminum coil is easy to withstand various pressure processing and extension and bending.

The Application of 1070 Aluminum Coil

1070 Aluminum coil is mainly used for alloy castings of structural parts such as aircraft wall panels, front beams, joints, pillars and landing gear, beauty equipment, and notebook casings.
