3005 Aluminum Sheet Plate

Alloy: 3005
Temper: O,H18,H24,H26,H28,H112,etc.
Width(mm): 100-2650
Thickness(mm): 1.00-500
Length(mm): 500-16000

Quick Quote Get A Quote

The Introduction of 3005 Aluminum Sheet Plate

3005 Aluminum sheet plate is an aluminum alloy with Mn as the main alloying element, is a kind of aluminum alloy that cannot be strengthened by heat treatment. Therefore, cold working method is used to improve its mechanical properties. Although the strength of this alloy is not very high, it is higher than the 1 series of industrial pure aluminum, and its strength is about 20% higher than 3003 aluminum plate, is also called anti-rust aluminum plate. It belongs to medium strength, good corrosion resistance, good plasticity and good welding performance. Flait Aluminum can produce all tempers of 3005 aluminum sheet, and controls the content of manganese between 1.0%-1.5%, making the 3005 aluminum sheet become a good rust-proof aluminum.

The Product Specification of 3005 Aluminum Sheet Plate

Alloy	3005 aluminum sheet plate
Temper	O,H12,H14,H16,H18,H19,H22,H24, H26,H28,H112,etc.
Thickness (mm)	1.0-500
Width (mm)	100-2650
Length (mm)	500-16000
Application	Color-coated aluminum substrates, lamp head materials, shutters, curtain walls, etc.

Chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Zr	Others		AL
3005	0.60	0.70	0.30	1.00-1.50	0.20-0.60	0.10	0.25	0.10	-	Single	Total	Balance
										0.05	0.15

The Product Features of 3005 Aluminum Sheet Plate

3005 aluminum plate has medium strength, good corrosion resistance, wide application and large dosage.
3005 aluminum plate has strong plasticity and is easy to form.
3005 Aluminum plate can be easily anodized, and the surface after anodizing is more conducive to color coating and other treatment in the later stage.
The surface quality of 3005 aluminum plate is good, no oil spots, waves, scratches, roll marks, neat trimming, no burrs.

The Application of 3005 Aluminum Sheet Plate

3005 aluminum plates are commonly used in humid environments such as air conditioners, refrigerators, and car bottoms. They are also commonly used in building materials, colored aluminum plates, kitchen utensils, food and chemical product processing and storage devices, tanks and tanks for transporting liquid products, and various pressures processed by thin plates, containers and pipes, general utensils, heat sinks, cosmetic panels, photocopier rollers, ship materials, battery shell materials, etc.

The Price of 3005 Aluminum Sheet Plate

The price of 3005 aluminum plate = aluminum ingot price + processing fee.

Note: 3005 aluminum plate has different tempers and specifications, the quotations of each aluminum plate manufacturer is also different. For detailed quotation, free online consultation is available, we are very happy to provide you with support and help!Click to Order
