Home > Product > Special Aluminum > 3105 Aluminum Sheet for Bottle Caps
For more detailed information including pricing, customization and shipping.
3105 aluminum sheet is an ideal material for making bottle caps, and is very suitable for making wine bottles, beverage bottles, soda water, juice, energy drinks and high-end cosmetics bottle caps. The main thickness of 3105 aluminum sheet for bottle caps is 0.15-0.30mm, and the tempers are H14, H16, H24, etc.
Compared with the 8011 aluminum plate for bottle caps, the 3105 aluminum sheet for screw caps has enough strength and can withstand larger gas pressure. 3105 aluminum sheet is widely used to make screw caps for vapor and liquid bottles, such as soda water and carbonated wine, etc. Also, the 3105 aluminum sheet for bottle caps can be printed in different colors and decorated with different styles of wine bottle caps and other bottle caps after being treated with chromium phosphate or DOS coating.
| Alloy | 3105 |
| Temper | H14,H24,H16,H26,H18 |
| Thickness | 0.15-0.50mm |
| Width | 500-1500mm |
| Surface Treatment | 1. Plain mill finish aluminum strip 2. DOS oil lubricated finish 3. Chromated finish 4. One side golden/white/red/blue/black,etc other colored, other side protective lacquered 5. Both sides clear/transparent lacquered |
| Samples | Free A4 size |
Chemical composition of 3105 aluminum sheet for bottle caps
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Ti | Others | Al |
| 3105 | ≤0.6 | ≤0.7 | ≤0.3 | 0.3-0.8 | 0.2-0.8 | ≤0.40 | ≤0.10 | ≤0.15 | Remainder |
Mechanical properties of 3105 aluminum sheet for bottle caps
| Alloy | Temper | Thickness(mm) | Tensile strength(Rm/Mpa) | Elongation(%) | Earring ratio (%) |
| 3105 | H14,H24 | 0.2-0.5 | 150-200 | 2 | 4 |
| 3105 | H16,H26 | 0.2-0.5 | 175-225 | 1 | 4 |
| 3105 | H18 | 0.2-0.5 | ≥195 | 1 | 4 |
Tolerance range of 3105 aluminum sheet for bottle caps
| Thickness (mm) |
Thickness tolerance(mm) |
Width tolerance | Length tolerance (mm) | Diagonal tolerance (mm) | Flatness (mm) | |
| ≤500mm | >500mm | |||||
| 0.15~0.48mm | -/+0.01mm | -/+1mm | -0/+2mm | -0/+1mm | ≤1mm | ≤5mm/2m |
| <3 wave/m | ||||||
◆ 3105 aluminum plate has good anti-rust properties, can be used for various bottle caps to achieve long-term beautiful effects.
◆ 3105 aluminum plate has excellent processing performance and deep drawing performance, can well meet the design requirements of different bottle caps.
◆ The good corrosion resistance of 3105 aluminum plate can well meet the internal and external environment of bottle caps.
◆ The strength, elongation and processing performance of 3105 aluminum sheet, can meet the requirements of high-strength automated bottle cap production process, and no creases or cracks will appear during the processing.
Beverage Closures: It is utilized for sealing caps on bottles, cans, and containers for beverages like water, soft drinks, and juices.Pharmaceutical Closures: The 3105 aluminum sheet is employed in the production of caps for pharmaceutical products, ensuring the integrity and safety of medicines.Cosmetic and Personal Care Closures: It finds application in caps and closures for cosmetics, skincare products, and personal care items, protecting the contents from contamination and preserving their quality.Red Wine Bottle Caps: It has enough strength to withstand gas pressure, can make screw caps for vapor and liquid bottles, such as soda water and carbonated wine, etc.
