5754 Aluminum coil is a typical alloy in the Al-Mg series alloy, magnesium alloy content is between 2.6-3.6%. It has the characteristics of medium strength, good corrosion resistance, weldability and easy processing and forming. 5754 aluminum plate is commonly used in the automobile manufacturing industry (car doors, molds, seals), tank truck industry (tanker body).
Alloy |
5754 aluminum coil strip |
Temper |
F,O,H111,H12,H14,H16,H18,H22,H24,H26, |
Thickness |
0.20-8.00 |
Width |
100-2650 |
Length |
C |
ID |
Ø505mm or customized |
Package |
Eye to sky or Eye to wall |
Certificate |
DNV,ABS,CCS,BV |
Application |
High-speed rail noise barriers, |
Sample |
Available |
Chemical composition:
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Ni |
Zn |
Ti |
Zr |
Al |
5754 |
0.40 |
0.40 |
0.10 |
0.50 |
2.60-3.60 |
0.30 |
|
0.20 |
0.15 |
|
Remainder |
Mechanical properties:
Alloy |
Temper |
Tensile strength Rm(Mpa) |
Yield strength Rp0.2(MPa) |
Elongation A(%) |
Hardness HBWα |
5754 |
O/H111 |
190-240 |
≥80 |
≥12 |
38 |
H32 |
220-270 |
≥130 |
≥11 |
- |
5754 aluminum coils are used in high-speed rail noise barriers, tank car materials, alloy doors and windows, aluminum for construction, aluminum for transportation, automotive stamping parts, aluminum for car insurance panels, etc.
