5754 Aluminum Sheet Plate

Alloy: 5754
Temper: O,H111,H112,H32
Width(mm): 100-2650
Thickness(mm): 0.10-600
Length(mm): 500-16000

5754 Aluminum Sheet Plate

Quick Quote Get A Quote

The Introduction of 5754 Aluminum Sheet Plate

5754 Aluminum sheet plate is AL-MG anti-rust aluminum, belongs to Almg3 series, magnesium alloy content is between 2.6-3.6%, has medium strength, good anti-rust and corrosion resistance, no color difference on anodized surface, excellent processing performance, good corrosion resistance, high fatigue strength, high weldability and moderate static strength. 5754 aluminum sheets in different heat treatment tempers are the main materials required in the automobile manufacturing industry (car doors, molds, seals) and tank trucks industry. We can provide different specifications of 5754 medium-thick aluminum plate, 5754 automotive aluminum plate, 5754 tank truck aluminum plate, 5754 patterned aluminum plate, 5754 ultra-wide aluminum plate.Click to Order

The Product Specification of 5754 Aluminum Sheet Plate

Alloy	5754 aluminum sheet plate
Temper	O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36, H38,H111,H112,H114,H116,H321,etc.
Thickness (mm)	0.10-600
Width (mm)	100-2650
Length (mm)	500-16000
Surface treatment	Rolled, checkered aluminum plate
Package	Export packaging (protective film, interleaved paper)
Certificate	CCS, DNV, ABS, BV
Application	Automotive stamping parts, pressure vessels, ship structures, transport tanks, car doors, battery covers, molds, seals, welding structures, etc.

Chemical composition：

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Zr	Al
5754	0.40	0.40	0.10	0.50	2.60-3.60	0.30	-	0.20	0.15	-	Remainder

Mechanical properties：

Alloy

Temper

Tensile strength

Rm(Mpa)

Yield strength

Rp0.2(MPa)

Elongation

A(%)

Hardness

HBWα

5754

O/H111

190-240

≥80

≥12

H32

220-270

≥130

≥11

The Product Features of 5754 Aluminum Sheet Plate

5754 aluminum plate has strong welding performance, low tendency of welding cracks, high strength of weld seam and base metal.
5754 aluminum plate is a medium-high strength aluminum alloy with good fatigue performance and corrosion resistance.
The surface quality of 5754 aluminum plate is good, smooth and free of cracks, corrosion spots and nitrate traces.
Flait Aluminum can customize 5754 aluminum plate with different thicknesses and shape according to customer needs.

The Application of 5754 Aluminum Sheet Plate

5754 aluminum plate is widely used in auto parts, welded structures, storage tanks, pressure vessels, trains, ship structures and offshore facilities, transportation tanks, etc.; 5754 aluminum plate is also used to require excellent processing performance, excellent corrosion resistance, high fatigue strength , high weldability and medium static strength occasions.

5754 Aluminum Sheet Plate Price

The price of 5754 aluminum plate = aluminum ingot price + processing fee.

Note: 5754 aluminum plate has different tempers and specifications, the quotations of each aluminum plate manufacturer is also different. For detailed quotation, free online consultation is available, we are very happy to provide you with support and help!Click to Order
