Brazing Aluminum Sheet Coil Strip

  • Alloys: 3003,4343,4045,4047,4104,4A13,7072
  • Tempers: O,H22,H24,H18,H111,H112,H116
  • Width(mm): 500-1070
  • Thickness(mm): 0.50-5.00
  • Length(mm): 500-2500



Brazing aluminum sheet coil strip

Introduction of Brazing Aluminum Sheet Coil Strip

Brazing aluminum sheet is also called aluminum alloy brazing sheet, aluminum brazing sheet, aluminum brazing composite sheet, aluminum brazing cladding sheet, etc., which belongs to a kind of aluminum sheet commonly used in industrial production. The main products of brazed aluminum sheets are 3xxx and 4xxx series aluminum alloy sheets. Brazed aluminum sheets are used in the fields of radiators for electronic appliances and automobile industry, such as: air conditioner condensers, radiators, radiators for electronic components, etc. Commonly used alloys for brazing aluminum plates coils strips are: 4045/3003, 4343/3003, 4045/3003/4045, 4343/3003/4343, 4343/3003/7072 and etc.







Brazing aluminum sheet coil strip

Flait Aluminum uses surface pretreatment process to mill the base/core alloys and cladding layer alloys ingots to ensure that there are no defects such as deep grooves, aluminum chips, slag inclusions, surface cracks, etc., and use physical and chemical methods to strictly clean the oil, dust and metal oxide film on the surface of the aluminum plate. Under the premise of ensuring the product quality, the aluminum brazing cladding sheet produced has no pores, cracks, welding tumors, etc., and has a bright surface, uniform weld and beautiful appearance.

Specification of Brazing Aluminum Sheet Coil Strip



Alloy

Core

3003 3003+Zn 3003MOD

Brazing clad for CAB

4343 4045 4047

Brazing clad for VAC

4104 4A13

Contact-water clad

7072

Temper

O,H12,H14,H16,H18,H22,H24,H26

Thickness (mm)

0.5~5.0mm

Width (mm)

500-1200mm

Length (mm)

C

Clad Rate

4-18% per side, or customer requested

Tensile Strength (MPa)

Depending on different material/temper

Yield Strength (MPa)

Depending on different material/temper

Elongation (%) Min

Depending on different material/temper

Packing

Export standard package

Normal Alloys Plates

4045/3003, 4343/3003, 4045/3003/4045, 4343/3003/4343, 4343/3003/7072 and etc.





Mechanical Property of Brazing Aluminum Sheet Coil Strip
Alloy Temper

Thickness

(mm)

Tolerance

(mm)

Clad Ratio

(%)

Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)Min Application
3003 H14 0.06~0.1 ±0.005 None 150~200 ≥120 1 Radiator fin and plate
4043/3003/4043 H14 0.06-0.1 ±0.005 8-12 150-200 ≥120 1
4045/3003/4045 H14 0.1~0.12 ±0.005 8-12 150-200 ≥120 1 Charge air cooler material
4343/3003 O 1.2-3.0 ±0.03 5-10 100-150 ≥45 25 Radiator fin and plate
4343/3003/7072 O 1.2-3.0 ±0.03 5-10 100~150 ≥45 25
4343/3003/4343 O 0.4-0.5 ±0.02 8-12 100-150 ≥45 27 Evaporator fin and plate
4045/3003/4045 O 0.8-1.2 ±0.03 8-12 100-150 ≥45 27
4045/3003/4045 O 0.5-0.8 ±0.02 15-20 100-150 ≥45 25 Oil cooler
4104/3003/4104 H14 0.6-0.8 ±0.02,±0.03 13-17,8~12 150-200 ≥120 3 Engineering machinery
4004/3003/4004 H14 0.6~0.8,1.2~1.5 ±0.02 ±0.03 13-17 8-12 150-200 ≥120 3
Note: Alloy, specification and mechanical property can be customized according to different requirements.





Alloy solidus/liquidus temperature and recommended brazing temperature
Aluminum Alloy Core Brazing Clad
3003 3003+Zn 3003+MOD 7072 4343 4045 4047 4A13 4104
Solidus Temperature /℃ 643 641 646 577 577 577 577 559
Liquidus Temperature /℃ 654 653 657 615 590 580 615 591
Recommended Brazing Temperature /℃ - - - 600-620 590-605 580-605 600-620 590-605

Advantages of Brazing Aluminum Sheet Coil Strip

  • High strength and excellent welding performance; good mechanical property and surface condition.
  • Good heat resistance and high temperature resistance, and has a certain corrosion resistance.
  • Excellent processing performance, small deformation and easy forming; excellent collapse resistance during brazing.
  • There are no pores, cracks and other phenomena in the welding, the surface of the welded joint is bright, and the fillet is even.
  • Flait Aluminum provides various specifications for fin and brazing aluminum plate coil strip.



Fundamental Brazing Sheet Cladding Structure

Brazing aluminum sheet coil strip

Brazing layer material: Al-Si alloys (4xxx Series)

Core material: Al-Mn alloys (3xxx Series), Al-Si-Mg Alloys (6xxx Series)

Sacrificial anode material (Anticorrosive coating): AL-Zn-Cr alloy (7072)

Application of Brazing Aluminum Sheet Coil Strip

  • Brazing aluminum sheets coils strips are widely used in the fields of dynamic heat exchangers such as new energy vehicles, construction machinery, rail transit, shipping and aviation, as well as static heat exchangers such as household air conditioners, commercial refrigeration, industrial heat exchange, and so on.
  • Typical application of brazing aluminum sheets coils strips is: radiator system and air conditioning system of traditional fuel vehicles and new energy vehicles.

Application of Brazing Aluminum Sheet Coil Strip
