The 5182 aluminum sheet is the latest high-magnesium alloy tanker which was born for the European road dangerous goods transportation agreement in recent years. It has high tensile strength and elongation, exceptional durability and corrosion resistance. 5182 Aluminum sheet plate combination of strength, formability, weldability, and corrosion resistance makes it an ideal choice for constructing fuel tankers that can withstand the demands of transportation while ensuring the safety and integrity of the fuel being transported. 5182 aluminum sheet plate is commonly used in the manufacturing of fuel tankers or tank trailers.
Alloy | 5182 |
Temper | O,H111,H112,H114,H116,H32,etc. |
Thickness (mm) | 4 – 8 |
Width (mm) | 1500 – 3450 Typical width: 1500/1600/1800/2000/2200/2400mm |
Length (mm) | 500 – 16000 Typical length: 5500/5750/6000/7500/7850/8600/11800mm |
Standards | GB/T 3880, EN14286, EN485, ASTM B209, or according to customer’s special requirements |
Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr |
5182 | 0.20 | 0.35 | 0.15 | 0.20-0.50 | 4.00-5.00 | 0.10 | – | 0.25 | 0.10 | – |
Mechanical properties
Alloy | Temper | Tensile strength Rm(Mpa) | Yield strength Rp0.2(MPa) | Elongation A(%) | Minimum Bending Radius of 180 Degree |
5182 | O/H111 | 280-350 | ≥125 | ≥26 | 1 Ton |
5182 aluminum plate is suitable for aluminum-magnesium alloy tankers used under high temperature conditions, with strong corrosion resistance.
